Keyed One Side
914 SmartCode Traditional Electronic Deadbolt with Z-Wave Technology
914TRL ZW 11P
The Locksmith's Choice.
We challenged locksmiths at the Associated Locksmiths of America (ALOA) to a picking and bumping contest pitted against the Kwikset SmartKey 980 Deadbolt.
Re-Key to any KW1 Keyway Key
While re-keying your door lock is not a requirement of lock installation, SmartKey allows you to quickly and easily reset your lock's cylinder to work with any KW1 Keyway key.
Integration Partners
Kwikset smart locks are offered by leading smart home solution providers and security systems. A total home security solution begins with a Kwikset smart lock. Complete your smart home today!
Alarm.com
LittleBird
SmartRent
Features
- For use on exterior doors where keyed entry and security is needed
- Featuring SmartKey Security™, which protects against advanced break-in techniques and allows you to re-key your lock yourself in seconds.
- SmartKey Security™ re-key technology is compatible with Kwikset (KW1) keyway
- Comes with 2 keys
- Latch is 20 minute fire rated with round corner face
- ANSI/BHMA grade 2 certified
- Latch has adjustable backset 2-3/8" to 2-3/4" to fit all standard door preparations
- Includes round deadbolt strike
- 1 inch deadbolt throw
- Locking mechanism functions with turn piece on the interior of the lock
- Meets or exceeds Underwriter Laboratories (UL) testing requirements specified for each product grade or rating
- Requires 4 AA batteries, included
- Keypad stays lit for 30 seconds after inactivity
- Expanding your security system solution with Home Connect technology, your keyless entry lock will now communicate wirelessly to security and home automation systems via Z-Wave
Compatible Technologies
-
Alexa
-
SmartThings
-
Vera
Similar Products
3 Finishes
Kevo Traditional Touch-to-Open Smart Lock, 1st Gen
3 Finishes
Signature Series Deadbolt (Square) with Home Connect with Z-Wave Technology
Signature Series
2 Finishes
919 Premis Traditional Smart Lock
2 Finishes
Signature Series Deadbolt (Round) with Home Connect with Z-Wave 500 Technology
3 Finishes
888 SmartCode Electronic Deadbolt with Z-Wave Technology
3 Finishes
Signature Series Deadbolt with Home Connect with Zigbee Technology
3 Finishes
912 SmartCode Electronic Tustin Lever with Zigbee Technology
3 Finishes
910 SmartCode Traditional Electronic Deadbolt with Zigbee Technology
3 Finishes
910 SmartCode Traditional Electronic Deadbolt with Z-Wave Technology
3 Finishes
916 SmartCode Traditional Electronic Deadbolt with Z-Wave Technology
3 Finishes
912 SmartCode Electronic Tustin Lever with Z-Wave Technology
2 Finishes
Halo Touch Traditional Fingerprint Wi-Fi Enabled Smart Lock
3 Finishes
914 SmartCode Traditional Electronic Deadbolt with Zigbee Technology
3 Finishes
916 SmartCode Traditional Electronic Deadbolt with Zigbee Technology
3 Finishes
Home Connect 620 Traditional Keypad Connected Smart Lock with Z-Wave Technology
Specifications
All Measurements are in Inches
-
Kwikset FamilySmartCode Deadbolts Touchpad with Home Connect
-
Product TypeDeadbolt
-
StyleTraditional
-
Entry Has SmartKey?Yes
-
Has Microban?Yes
-
ANSI GradeGrade 2
-
UL Time Rating20 min
-
Min Door Thickness1-3/8
-
Max Door Thickness2
-
Assembled Height4-7/16
-
Assembled Width2-5/8
-
Assembled Length1.75
-
Latch Backset SizeAdjustable
-
Cross Bore2-1/8"
-
ADA CompliantNo
-
Voice Control EnabledAlexa via Samsung SmartThings ; Alexa via Wink Hub ; Google Assistant via Samsung SmartThings ; Google Assistant via Wink hub
-
Lock TechnologyZ-Wave500
-
Hub RequiredRequires Smart Hub
-
Electronic Works WithVera ; Alexa ; SmartThings
-
# Of Codes30
-
Battery Type Required4 AA, included
Support
Documents
Note: Do not use prints from this website to mark distances. Due to individual printers, dimensions on installation instructions may not print at an accurate scale.
