Keyed Both Sides
Tylo Security Set - Deadbolt Keyed Both Side - with Pin & Tumbler
695T 5
Features
- Keyed Deadbolt: Use on doors requiring a high level of security, turn piece interior locking, exterior locking using a key. Recommended for exterior-facing doors
 - Smartkey Security: Kwikset’s SmartKey® Security technology protects against advanced break-in techniques and allows you to re-key your lock yourself in seconds
 - Easy Install: Do it yourself, installs in minutes with just a screwdriver, all the hardware you need is included for a hassle-free installation, detailed directions provided
 - Fits Standard Doors: Fits standard size doors 1-3/8" to 1-3/4" thick, latch backset adjusts to either 2-3/8" or 2-3/4" with just a twist during installation
 - Certified Trusted Quality: Security, Durability and Finish are Grade 3 BHMA certified, designed for reliable protection, providing peace of mind at home
 - Box Includes: Box includes deadbolt, adjustable latches with round and square front options or drive-in collar, round corner strikes, SmartKey® tool, 2 Kwikset keys, screws and Allen wrench
 - Warranty Protection: Our products are backed by a lifetime mechanical and finish warranty with great customer service, see Kwikset warranty for more details

Specifications
All Measurements are in Inches
-
									Kwikset FamilyTylo
 -
									Product TypeKnob
 -
									StyleTraditional
 -
									Entry Has SmartKey?No
 -
									Has Microban?Yes
 -
									ANSI GradeGrade 3
 -
									UL Time RatingNot rated
 -
									Min Door Thickness1-3/8
 -
									Max Door Thickness1-3/4
 -
									Assembled Height2-5/8
 -
									Assembled Width2-5/8
 -
									Assembled Length2-1/2
 -
									Cross Bore2-1/8"
 -
									ADA CompliantNo

Support
Documents
Note: Do not use prints from this website to mark distances. Due to individual printers, dimensions on installation instructions may not print at an accurate scale.
