Ashfield Lever - Hall/Closet

720ADL 501

Enlarge Photo

Discontinued

Product Image - kw_ad-lv-pass-501-ex
Product clippedImage - kw_ad-lv-pass-501-ex
Product clippedImage - kw_ad-lv-pass-501-int
Product Vignette - kw_tu_ashfield_720adl-501_v1
Function:

Hall and Closet

Features

  • Designer style and superior security with this Kwikset Signature Series™ product
  • For use on interior doors requiring no locking functionality, such as hallway or closet doors
  • Latch has 2 interchangeable faceplates; round corner and square corner
  • Meets ADA/ANSI A117.1 requirements, ensuring accessibility to all disabled persons
  • ANSI/BHMA grade 2 certified
  • Latch has adjustable backset 2-3/8" to 2-3/4" to fit all standard door preparations
  • Fully reversible lever, can be installed on both right handed and left handed doors
  • Easily installs in minutes with just a screwdriver
  • Lifetime mechanical and finish warranty

Specifications

All Measurements are in Inches

  • Kwikset Family
    Ashfield
  • Product Type
    Lever
  • Entry Has SmartKey?
    No
  • Has Microban?
    No
  • ANSI Grade
    Grade 2
  • Min Door Thickness
    1-3/8
  • Max Door Thickness
    1-3/4
  • Assembled Height
    4-3/16
  • Assembled Width
    2-5/8
  • Assembled Length
    2-9/16
  • Lever Handling
    Reversible
  • Cross Bore
    2-1/8"
  • ADA Compliant
    Yes

Support

Documents

Note: Do not use prints from this website to mark distances. Due to individual printers, dimensions on installation instructions may not print at an accurate scale.
