915 Smartcode Traditional Electronic Deadbolt

915TRL L03

Enlarge Photo

Discontinued

Product Image - kw_915trl-sl-db-l03-ex
Product clippedImage - kw_915trl-sl-db-l03-int-1
Product clippedImage - kw_915trl-sl-db-l03-int-2
Product Vignette - kw_915trl-sl-db-l03-cb
Product Vignette - kw_915trl-sl-db-3-v1
Function:

Keyed One Side

  • USER CODES

    Assign customized user codes for easy management of who has access to your home

  • ONE TOUCH LOCKING

    Improved user access code management (optional)

  • ANSI/BHMA RATED

    BHMA Grade 2 Certified

  • AUTO LOCK

    Forget to lock your door? Set your 915 to auto-lock after 30 seconds for peace of mind.

The Locksmith's Choice.

We challenged locksmiths at the Associated Locksmiths of America (ALOA) to a picking and bumping contest pitted against the Kwikset SmartKey 980 Deadbolt.



Re-Key to any KW1 Keyway Key

While re-keying your door lock is not a requirement of lock installation, SmartKey allows you to quickly and easily reset your lock's cylinder to work with any KW1 Keyway key.

Features

  • The advanced Capacitive touchscreen touchscreen is ultra responsive to touch for instant screen display and features cool white LEDs for defined illumination
  • Bright white LED’s for clear visibility in the brightest sunlight
  • Secured keyless entry convenience
  • One touch locking
  • Dramatically reduced interior size and sleek metal design
  • 16 user codes plus master code feature for added security
  • BHMA grade 2 certified
  • 20 minute fire rating - UL certified
  • SmartKey® technology - the lock you can re-key yourself in seconds in three easy steps
  • SmartKey® re-key technology is compatible with Kwikset (KW1) keyway
  • Patented Bump proof and Pick resistant side locking bar technology
  • Installs in minutes with just a screw driver no hard wiring needed
  • Fits standard doors (1-3/8in. – 2in.) no new screw holes required
  • Tamper resistant interior

Similar Products

Powerbolt Electronic Deadbolt

3 Finishes

Powerbolt Electronic Deadbolt
909 SmartCode Traditional Electronic Deadbolt

3 Finishes

909 SmartCode Traditional Electronic Deadbolt
913 Smartcode Traditional Electronic Deadbolt

3 Finishes

913 Smartcode Traditional Electronic Deadbolt
911 SmartCode Electronic Lido Lever

1 Finishes

911 SmartCode Electronic Lido Lever
911 SmartCode Electronic Tustin Lever

3 Finishes

911 SmartCode Electronic Tustin Lever
260 SmartCode Traditional Electronic Deadbolt

3 Finishes

260 SmartCode Traditional Electronic Deadbolt
Signature Series
Powerbolt 240 Traditional Keypad Electronic Lock

3 Finishes

Powerbolt 240 Traditional Keypad Electronic Lock

Specifications

All Measurements are in Inches

  • Kwikset Family
    SmartCode Deadbolts Touchscreen
  • Product Type
    Deadbolt
  • Style
    Traditional
  • Entry Has SmartKey?
    Yes
  • ANSI Grade
    Grade 2
  • Min Door Thickness
    1-3/8
  • Max Door Thickness
    1-3/4
  • Assembled Height
    5-3/4
  • Assembled Width
    2-3/4
  • Latch Backset Size
    Adjustable
  • Cross Bore
    2-1/8"
  • ADA Compliant
    No
  • # Of Codes
    16
  • Battery Type Required
    4 AA, purchase separately
DimensionsImage

Support

Documents

Note: Do not use prints from this website to mark distances. Due to individual printers, dimensions on installation instructions may not print at an accurate scale.
